Size:450 x 600mm
Capacity: 98L
Construction :
The outer and inner Chamber is made of 304 grade Stainless Steel. Lid is made of S. Steel with inside lined with S.S. for double protection. The unit has Radial Locking arrangement for the lid. Provided with built-in safety valve, pressure gauge, pressure release valve. Pressure is adjustable from 5 psi to 30 psi ± 3 psi. Supplied complete with cord, plug etc. To operate 220 volts single phase 50 cycles.
Mode of Heating :-
Electrically heated by special flange type/immersion type heaters bearing ISI mark, to work on 220 volts single phase 50 cycles.
Working Pressure:
The normal recommended pressure for sterilization process is 1.2 kgf/cm sq.g ( 15 psi - 30psi )
Working Temperature : 121° C
Hydro test Pressure : 2.5 kgf/cm sq.g ( 35 psi )
Standard Controls :
OPTIONAL ACCESSORIES AT EXTRA COST
SIZES AVAILABLE
