Use: traversing, setting out
Measuring range:
Single prism: 5000m
Triple prism: 8000-10,000m
Mini prism: 800m
Accuracy: with prism 2mm+2ppm without prism 3mm+2ppm
Digital display: Maximum 99999999.9999 - Minimum 0.1mm
Measuring time: Tracking 0.1S, Fine 0.3S (Optimal)
Atmospheric correction: Automatic correction by inputting Parameter
Prism constant: Automatic correction by inputting Parameter
Angle Measurement:
Measurement method: Absolute Encoding
Diameter of the raster disk: 79mm
Minimum reading 1” / 5” Optional
Accuracy 5”
Detection method: Horizontal: Dual – Vertical : Dual
Telescope:
Image: Erect
Length: 154mm
Effective aperture: 45mm, (DTM: 50mm)
Magnification: 30X
Field of view : 1° 30’
Resolving power: 3”
Minimum focus: 1m
Compensation:
System: Dual axis liquid-electric
Working range: ±3’
Resolving power: 1”
Sensitivity of Vials:
Plate vial: 30” / 2mm
Circular vial: 8’ / 2mm
Optical Plummet:
Image: Erect
Magnification: 3X
Focusing range: 0.5m to ?
Field of view: 5°
Data storage & communications:
Internal memory: 2M/ 24000 points
External memory: SD card (upto 32GB)
Communication port: RS-232, mini USB
Display: Dual side, 6 lines
Battery: Rechargeable Ni-H (2700mAh), 6VDC, 10 Hrs continuous operation.
Dust/Water (IEC 60529) : IP 56
Weight: 5.8Kg
Accessories:
